Dual-Pump Hydraulics: 35cc main pump + 25cc auxiliary pump enable 58-second full extension, with proportional control valves for 0.1m/s precision movements.
±150° Jib Articulation: Navigates obstacles like overhangs and utility lines, supported by a laser alignment system (±0.2° accuracy).
Insulated Platform: IP66-rated, with anti-slip flooring and 360° fall arrester points, compliant with EN 361 fall protection standards.
Automatic Outrigger System: Front span 5.3m + rear 5.0m, self-leveling on ≤8° inclines within 20 seconds, with hydraulic lock indicators.
Dynamic Load Monitoring: Real-time LMI displays load percentage, boom angle, and wind speed (alarms at ≥12m/s), auto-shutting down at 105% capacity.
Collision Avoidance: 8m ultrasonic sensors on boom tips prevent contact with obstacles during movement.
Emergency Power Unit: 12V backup battery lowers the platform in 90 seconds during main power failure.
360° Vision System: 4x HD cameras with 180° rear-view assist, reducing blind spots by 90%.
Fire Suppression: Automatic engine bay extinguisher triggered by temperature sensors.
Ergonomic Cab: Air-suspended seat with 8-way adjustment, lumbar support, and climate control (-20°C to +50°C).
Smart Control Panel: 10-inch touchscreen with GPS, maintenance alerts, and 3 preset boom positions for repetitive tasks (e.g., streetlight maintenance).
Dual Control Modes: Ground-mounted joystick + radio remote control (100m range) with haptic feedback for precision in confined spaces.
Night Work Kit: 6x 1,500-lumen LED floodlights, meeting OSHA 1910.269 lighting requirements for nighttime operations.
Corrosion Resistance: 5-layer electrophoretic paint (锌层厚度≥8μm) passes 1,500-hour salt spray test, suitable for coastal and industrial zones.
Low-Maintenance Hydraulics: Self-cleaning spin-on filters (β10(c) ≥ 200) extend oil life to 4,000 hours—double the industry average.
Heavy-Duty Tires: 245/70R19.5 all-steel radials (14PR) with reinforced sidewalls, tested for 500,000 km on gravel roads.
Emissions Compliance: Euro V, EPA Tier 4 Final, and China VI (with DPF/SCR options).
Regional Adaptations:
Cold climates: Block heater (-35°C start capability).
High humidity: Waterproof electrical connectors (IP67 rating).
Modular Upgrades:
Insulated Boom: Rated for 35kV live-line work (符合 IEC 60855 standards).
Material Hoist Attachment: Converts platform to 500kg cargo lift for construction sites.
Telematics Module: Real-time data on fuel consumption, boom usage, and geofencing.
