Certified Aircraft Refueling Truck: Jiefang 8.5CBM with JIG 1 & ICAO Annex 18 Compliance

Brand FAW
Product origin HUBEI
Delivery time >42
Supply capacity >1

The Jiefang 4x2 8.5CBM Aircraft refueling truck, powered by a Dachai 180HP engine and Shaanxi 8-speed gearbox, delivers precision aviation fueling. This Aircraft refueling truck features 3-stage filtration (ISO 16/13 purity), 4-minute 8.5CBM transfer, and 8m static grounding. With ABS, 360° cameras, JIG 1/ICAO Annex 18 certifications, this Aircraft refueling truck ensures safe, efficient airport operations—trusted for global aviation logistics.

Aircraft refueling truck

tanker truck

Oil tank truck

Aircraft refueling truck

Dachai 180HP Engine: Power with Controlled Efficiency

At the core of this Aircraft refueling truck lies the reliable Dachai CA6DE1-18E5 diesel engine, delivering 180 horsepower and 650Nm of torque at 1,400-1,800rpm. This engine is uniquely calibrated for the stop-start demands of aviation fueling, offering:

Instant Throttle Response: Essential for making precise positioning adjustments near aircraft, minimizing the risk of contact with sensitive components.
Fuel Efficiency: A remarkable 21L/100km consumption rate—12% better than comparable Aircraft refueling trucks—reducing operational costs for fleet operators.
Altitude Adaptability: Equipped with a variable-geometry turbocharger, it maintains consistent performance at high-elevation airports where thinner air can compromise standard engines.

Paired with a Shaanxi 8-speed manual transmission, the engine delivers seamless power across all operating ranges. The transmission’s close-ratio lower gears provide precise low-speed control during fueling, while its overdrive 8th gear reduces highway RPM by 20%, lowering noise and extending engine life.

8.5CBM Tank: Aviation-Grade Fuel Integrity

The 8.5-cubic-meter tank is the Aircraft refueling truck’s critical component, engineered to meet aviation’s strictest fuel containment standards. Constructed from 16MnDR pressure vessel steel (ASME BPVC Section VIII certified), it features 6mm walls with a 3-layer epoxy-phenolic lining that resists corrosion from Jet A-1, JP-8, and other aviation fuels.

Advanced Purity Systems

3-Stage Filtration: 10μm pre-filter → 5μm fine filter → 3μm polishing filter removes contaminants to ISO 4406 Class 16/13—the standard required by Boeing, Airbus, and all major aircraft manufacturers.
Water Separation: Integrated system removes moisture to prevent ice formation in aircraft fuel systems during high-altitude flights.
Overfill Prevention: Float sensors trigger alarms at 95% capacity, automatically stopping fuel intake to prevent spills (EN 13922 compliant).

Rapid Fuel Transfer Technology

This Aircraft refueling truck features a high-performance transfer system designed to minimize aircraft turnaround time:

2,500L/min Gear Pump: Empties the full 8.5CBM tank in just 4 minutes—critical for busy commercial airports.
18m Hydraulic Hose Reel: Aviation-grade DN50 hose with NATO-standard dry-break coupling prevents spills when disconnected.
Precision Metering: Electronic flow meter with ±0.2% accuracy (NIST calibrated) displays volume in liters and gallons for international operations.

An intuitive cab control panel allows operators to monitor pressure, flow rate, and total volume with one-touch activation for all systems.

Comprehensive Safety Features

Safety is paramount in aviation fueling, and this Aircraft refueling truck delivers multiple layers of protection:

Static Control: 8m grounding cable with 10Ω resistance clamp eliminates ignition risks from electrostatic discharge.
Fire Suppression: 2x 6kg ABC extinguishers plus automatic engine bay suppression system activating in 2 seconds.
Emergency Shutdown: Red panic buttons at all vehicle corners instantly halt operations.
Active Safety:

ABS + EBD prevents wheel lock on wet tarmacs, reducing stopping distance by 15%.
Programmable speed limiter (40km/h apron / 80km/h road) meets IATA regulations.
360° cameras eliminate blind spots when maneuvering near aircraft.

Tags:

When was Hubei Shengda Automobile Co., Ltd. established, and what is its main business?

The company was founded on May 23, 2013. It mainly engages in the sales, import, and export of special vehicles (e.g., tanker trucks, sanitation vehicles, dangerous goods vans), construction machinery, auto parts, as well as the manufacturing of special vehicle equipment and molds.
What products does Hubei Shengda Automobile provide?

Its main products include tanker trucks, sanitation vehicles, dangerous goods enclosed trucks, cylinder transport vehicles, and collision - avoidance buffer trucks. The company also offers customized manufacturing and import - export services for these products.
What services are available when buying vehicles from the company?

The company provides a one - stop service covering customization, exchange, return, installment payment, vehicle registration assistance, and door - to - door delivery.
Which countries and regions are the products exported to?

The products have already reached markets in Europe, America, Vietnam, North Korea, and Southeast Asia. It is continuously expanding into emerging markets like the Middle East and South America. The company can adapt to the regulatory standards (such as environmental protection and safety certifications) of the customers' regions.
