Jiefang 4x2 8.5CBM Refueler: Shaanxi Gearbox & 3-Stage Filtration for Jet Fuel Purity

  • FAW
  • HUBEI
  • >45
  • >1
The Qixing 4x2 Jiefang 8.5CBM Aircraft refueling truck combines a Dachai 180HP engine and Shaanxi 8-speed gearbox for precision aviation fueling. This Aircraft refueling truck features 3-stage filtration (ISO 16/13 purity), 4-minute 8.5CBM transfer, and 8m static grounding. With ABS, 360° cameras, and JIG/ICAO certifications, this Aircraft refueling truck ensures safe, efficient airport operations—ideal for global airlines and fuel suppliers.

Aircraft refueling truck

tanker truck

Oil tank truck

Aircraft refueling truck

4x2 Chassis: Maneuverability Tailored for Airport Aprons
The backbone of this Aircraft refueling truck is its 4x2 Jiefang chassis, meticulously engineered for the tight confines of airport environments. With a 3,800mm wheelbase, it achieves an impressive 8.5-meter turning radius—significantly tighter than standard commercial trucks—allowing operators to navigate seamlessly between aircraft stands, terminal gates, and fuel storage areas. The chassis is constructed from high-strength low-alloy steel, striking the perfect balance between durability and weight efficiency, which enhances fuel economy during road transit to and from airport fuel depots.
Reinforced crossmembers and a reinforced frame ensure the chassis can safely support the 8.5CBM tank and associated equipment, even when fully loaded. This structural integrity is critical for withstanding the constant vibrations and weight shifts encountered during daily airport operations, extending the Aircraft refueling truck’s service life to an impressive 20+ years with proper maintenance.
Dachai 180HP Engine: Power with Precision Control
At the heart of this Aircraft refueling truck lies the robust Dachai CA6DE1-18E5 diesel engine, delivering 180 horsepower and 650Nm of torque at 1,400-1,800rpm. This engine is uniquely calibrated for the stop-start demands of aviation fueling, offering:
  • Instant Throttle Response: Essential for positioning the Aircraft refueling truck with millimeter precision alongside aircraft fuel inlets, minimizing the risk of contact with sensitive aircraft components.

  • Fuel Efficiency: A remarkable 21L/100km fuel consumption rate—12% more efficient than comparable Aircraft refueling trucks—reducing operational costs for fleet operators.

  • Altitude Adaptability: Equipped with a variable-geometry turbocharger and air-to-air intercooler, it maintains consistent power output at high-elevation airports like those in the Andes or Himalayas, where oxygen levels can reduce engine performance.

Paired with a Shaanxi 8-speed manual transmission, the engine delivers seamless power distribution across all operating ranges. The transmission’s close-ratio gears provide precise low-speed control during fueling operations, while its overdrive 8th gear reduces engine RPM by 20% during highway travel, lowering noise levels and extending engine life.
8.5CBM Tank: Aviation-Grade Fuel Containment & Purity
The 8.5-cubic-meter fuel tank is the Aircraft refueling truck’s core component, engineered to meet the stringent requirements of aviation fuel storage. Constructed from 16MnDR pressure vessel steel—certified to ASME BPVC Section VIII standards—it features:
  • Corrosion Resistance: 6mm-thick tank walls with a 3-layer epoxy-phenolic lining, specifically formulated to resist the corrosive effects of Jet A-1, JP-8, and other aviation fuels, ensuring long-term integrity.

  • Fuel Purity Systems: A 3-stage filtration process (10μm pre-filter → 5μm fine filter → 3μm polishing filter) removes contaminants to meet ISO 4406 Class 16/13 standards—the strict purity level required by Boeing, Airbus, and other aircraft manufacturers.

  • Rapid Transfer Capability: A high-performance 2,500L/min gear pump, driven by the truck’s power take-off (PTO), empties the full 8.5CBM tank in just 4 minutes, minimizing aircraft turnaround time—a critical metric for busy commercial airports.

Safety-Enhancing Tank Features
  • Static Electricity Control: An 8-meter retractable grounding cable with a 10Ω resistance clamp ensures continuous electrical bonding between the Aircraft refueling truck and aircraft, eliminating the risk of sparks that could ignite fuel vapors.

  • Overfill Prevention: A float-level sensor triggers visual and audible alarms when the tank reaches 95% capacity, automatically shutting off the loading valve to prevent spills—compliant with EN 13922 aviation safety standards.

  • Vapor Recovery: An integrated vapor recovery system captures and returns 98% of fuel vapors during loading, reducing emissions and meeting EPA and EU environmental regulations.

Advanced Fueling Systems for Seamless Operations
This Aircraft refueling truck is equipped with specialized systems that streamline the fuel transfer process:
  • Hydraulic Hose Reel: A 18-meter-long DN50 aviation-grade fuel hose, mounted on a hydraulic reel, provides flexible reach to aircraft fuel inlets. The hose features a NATO-standard dry-break coupling that automatically seals when disconnected, preventing fuel spills.

  • Precision Metering: An electronic flow meter with ±0.2% accuracy—calibrated to NIST standards—displays real-time fuel volume in both liters and gallons, ensuring accurate billing and inventory tracking for international operations.

  • Integrated Control Panel: A weatherproof control panel in the cab allows operators to monitor fuel pressure, flow rate, and total volume transferred, with one-touch activation for the pump and reel systems.







tanker truckOil tank truckAircraft refueling truck



  • When was Hubei Shengda Automobile Co., Ltd. established, and what is its main business?

    The company was founded on May 23, 2013. It mainly engages in the sales, import, and export of special vehicles (e.g., tanker trucks, sanitation vehicles, dangerous goods vans), construction machinery, auto parts, as well as the manufacturing of special vehicle equipment and molds.

  • What products does Hubei Shengda Automobile provide?

    Its main products include tanker trucks, sanitation vehicles, dangerous goods enclosed trucks, cylinder transport vehicles, and collision - avoidance buffer trucks. The company also offers customized manufacturing and import - export services for these products.

  • What services are available when buying vehicles from the company?

    The company provides a one - stop service covering customization, exchange, return, installment payment, vehicle registration assistance, and door - to - door delivery.

  • Which countries and regions are the products exported to?

    The products have already reached markets in Europe, America, Vietnam, North Korea, and Southeast Asia. It is continuously expanding into emerging markets like the Middle East and South America. The company can adapt to the regulatory standards (such as environmental protection and safety certifications) of the customers' regions.
